Parameter Settings
6-49
Calculated Values
This menu allows you to view the values calculated from the analog input signal
selected previously in the unit.
Calculated values
I/O: Digital Inputs
This menu enables you to view digital input values routed to the transmitter input
clamps. It indicates either OFF or ON.
Digital input values
I/O: Analog Outputs
Analog input values
This menu allows you to view the calculated voltage that will be sent to the analog
converter.
I/O: Digital Outputs
This menu allows you to view the conditions detected by the transmitter and routed to
the relay. It indicates either OFF or ON.
Digital values
