Page 30
System Overview and Operation
2-9
1
Plug with Spigot Nut (optional)
2
Sensor Cable
3
Sensor Body
4
Ground Plate
5
Cable Gland
6
Sensors for Depth Measurement using Air-Ultrasonic
Air-Ultrasonic Depth Sensor
1
2
3
4
1
Ground Plate 1 (optionally removable)
2
Ground Plate 2 (base plate)
3
Ground Plate 3 (spacer plate)
4
Cut-out for Pipe Mounting Plate
Air-Ultrasonic Depth Sensor
