Parameter Tree B-7
Signal Input/Output Menu (I/O)
I/O
analog inputs
values in [mA/V] indicates value tables A1 - 4
digital inputs indicates value table D1
analog outputs indicates value table A1 in [V]
digital outputs indicates value table D1
sensors
v-sensor indicates 2-page value table h1 - 16
h-sensor(s) indicates values from single level sensors
indication mode depends on previously programmed sensors
level indicates the level currently used
water US
pressure
analog I
air US
h-echo profile indicates envelope as graph (reflections)
t-sensor indicates air and water temperature in [°C]
interfaces indicates GPRS signal quality
MemoryCard
info information on type of memory card, memory and remaining capacity
format card card formatting, all data saved on card will get lost
strore parameter transmitting settings from PCM 4 to memory card
restore parameter writes settings from memory card to PCM 4
store backup will save internal memory on card (back up function)
day totals will save day totals on memory card
system indicates various data and information on
rechargeable battery used
