Calibration Menu (CAL)
CAL
level
calibration option to calibrate level sensors
by entering a reference value
velocity
min. + max. value
min. value -0.500m/s minimum velocity possible
max. value 4.000m/s maximum velocity possible
h_krit H-crit:0.000 input of H-critical in [m] and V-critical in [m/s]
auto. discharge curve yes toggle between automatic YES/NO
V-crit determination
Manning-Strickler
kst
Ie [%]
80 Manning - Strickler coefficient
0.3 slope at measurement point
Manuell manual entry of h and v
Assistant calibration assistant
analog outputs
simulation
K1 V 0 direct reading output
digital outputs turn relay On or OFF by using
arrow keys up or down
simulation simulation of fill level with arrow keys up or down
v simulation with arrow keys right or left
output of calculated simulation value
