System Overview and Operation 2-11
Mini Air-Ultrasonic Depth Sensor
1 Ground Plate
2 Sensor for Depth Measurement using Air-Ultrasonic
3 Sensor Body
4 Cable Gland
5 Sensor Cable
6 Connector with Spigot Nut
7 Fastening Clamp for Ceiling Installation
Mini Air-Ultrasonic Depth Sensor
1 Ground Plate 1
2 Ground Plate 2 (base plate)
3 Ground Plate 3 (spacer plate)
4 Cut-out for Pipe Mounting Plate
Mini Air-Ultrasonic Depth Sensor
