6-10 ADS Portable FlowShark Pulse Manual
1 Measurement window
2 Velocity value
3 Velocity measurement window number
4 Depth (level) value
5 Depth (level) measurement window number
6 Maximum velocity
7 Maximum height
Flow velocity distribution
Very good profile, area
free of backwater
Good profile, strongly
tending to backwater formation
or very high flow velocity
Suitable profile
Poor profile Unsuitable profile
Flow velocity profiles
RUN: Day Values
This menu indicates the day total values and provides information concerning partial
totals since the last reset (similar to the route mileage counter in a car).
View day total values for the past 90 days through the INFO menu. The system saves
the flow totals to memory for 90 days. You can save this data to the compact flash
card through the I/O menu.
