Specifications A-9
Depth Measurement
Measurement
Range
0 to 78.7 inches (0 to 200 cm)
Dead Band (from
grounding plate)
1.57 inches (4 cm)
Measurement Error less than ±0.2 inches (±5 mm)
Temperature Measurement
Measurement
Range
-4° to 122° F (-20° to +50° C)
Measurement Error ±1° F (±0.5° K)
Dimensions for Mini Air-Ultrasonic Sensor in millimeters
X represents the holder for direct fastening
Y represents the cut-out for fastening on pipe mounting system
