GRoUps and channels
All serial commands use common alpha and numeric designators to reference channel groups, channel types, and
other command values. Also, different channel groups have different allowable channel ranges, as shown in the
following table.
Group
Alpha
number
Converge
pro 880
Channel
range
Converge
pro TH20
Channel
range
Converge
pro 840T
Channel
range
Converge
pro 8i
Channel
range
Converge
880T
Channel
range
Converge
Sr 1212
Channel
range
unknown
?
0
n/A
n/A
n/A
n/A
n/A
n/A
inputs
i
1
1-12
1-2
1-8
1-12
1-12
1-12
outputs
o
2
1-12
1-2
1-9 (9 is
the power
amp)
n/A
1-13 (13 is
the power
amp)
1-12
mic input
m
3
1-8
n/A
1-4
1-8
1-8
1-8
Gating
Group
G
4
A-d, 1-4
n/A
A-d, 1-4
A-d, 1-4
A-d, 1-4
A-d, 1-4
processing
p
5
A-H
n/A
A-d
A-H
A-H
A-H
expansion
Bus Audio
Channels
e
6
o-Z
o-Z
o-Z
o-Z
o-Z
o-Z
line inputs
l
7
9-12
1-2
5-8
9-12
9-12
9-12
expansion
Bus
reference
Channels
A
8
1-4
1-4
1-4
1-4
1-4
1-4
unit
u
9
0
1 = loG
2 = Site
Wide
0
1 = loG
2 = Site
Wide
0
1 = loG
2 = Site
Wide
0
1 = loG
2 = Site
Wide
0
1 = loG
2 = Site
Wide
0
1 = loG
2 = Site
Wide
Gpio
Y
10
0
0
0
0
0
0
matrix
x
11
0
0
0
0
0
0
Fader
F
12
1-4
n/A
1-4
1-4
1-4
1-4
presets
S
13
1-32
1-32
1-32
1-32
1-32
1-32
macros
C
14
1-255
1-255
1-255
1-255
1-255
1-255
Transmit
T
16
n/A
1
1
n/A
1
n/A
receive
r
17
n/A
1
1
n/A
1
n/A
dictionary
d
18
0
0
0
0
0
0
phonebook
V
19
n/A
0
0
n/A
0
n/A
Virtual
reference
B
20
1 – 4
n/A
1 – 4
1 – 4
1 – 4
1 – 4
Timed
events
Q
21
0
0
0
0
0
0
Web
W
22
0
0
0
0
0
0
