TORCH DATA for Ultra-Cut
8-16
Manual 0-4828
Rev BA
Aluminum
Flow Rates
50A
N₂ (SLPM / SCFH)
H₂O (GPH / LPH)
Preflow
26 / 56
4 / 15
N₂ Plasma / H₂O Shield
Cutflow
18 / 38
4 / 15
Shield Cup
Shield Cap
Shield Gas
Distributor
Tip
Plasma Gas Distributor
Electrode
Cartridge
21-1016
21-1034
21-1274
21-1180
21-1041
21-1181
21-1020
GCM-2010
SC-3000 Torch Height Control (THC)
Basic THC
CNC Control
Material
Thickness
Pre Flow
Pressure
(N2)
Cut Flow Rates / Pressures
Arc
Voltage Cut Height
THC
Pierce
Delay
Pierce
Ignition
Height
Elevation
Height
Control
Delay
Pierce
Height
without
Elevation
Travel
Speed
CNC
Motion
Delay
Max Kerf Width
@ Rec. Speed
Plasma (N₂) Shield (H₂O)
ga
(in)
inch
(psi)
Ball (psi) Ball (psi)* (Volts) (in) ±0.005 (sec)
(in)
(in)
(sec)
(in)
(ipm)
(sec)
(in)
-
-
0.064
100
60 120
4
55
128
0.110
0.0 0.125 0.120
0.5
0.200
140
0.0
0.045
-
-
0.079
100
60 120
4
55
127
0.110
0.1 0.125 0.120
0.5
0.200
117
0.1
0.045
-
-
0.097
100
60 120
4
55
131
0.110
0.2 0.125 0.120
0.5
0.200
90
0.2
0.046
-
-
0.120
100
60 120
4
55
135
0.110
0.2 0.125 0.120
0.5
0.200
60
0.2
0.050
- 16/85 0.188
100
60 120
4
55
140
0.120
0.3 0.125 0.120
0.5
0.200
40
0.3
0.051
GCM-2010
SC-3000 Torch Height Control (THC)
Basic THC
CNC Control
Material
Thickness
Pre Flow
Pressure
(N2)
Cut Flow Rates / Pressures
Arc
Voltage Cut Height
THC
Pierce
Delay
Pierce
Ignition
Height
Elevation
Height
Control
Delay
Pierce
Height
without
Elevation
Travel
Speed
CNC
Motion
Delay
Max Kerf Width
@ Rec. Speed
Plasma (N₂) Shield (H₂O)
(mm)
(Bar)
Ball (Bar) Ball (Bar)* (Volts) (mm) ±0.1 (sec) (mm)
(mm)
(sec)
(mm)
(mm/
min)
(sec)
(mm)
2
6.9
60
8.3
4
3.8
127
2.8
0.1
3.2
3.0
0.5
5.1
2990
0.1
1.1
2.5
6.9
60
8.3
4
3.8
131
2.8
0.2
3.2
3.0
0.5
5.1
2240
0.2
1.2
3
6.9
60
8.3
4
3.8
135
2.8
0.2
3.2
3.0
0.5
5.1
1590
0.2
1.3
4
6.9
60
8.3
4
3.8
138
2.9
0.3
3.2
3.0
0.5
5.1
1240
0.3
1.3
5
6.9
60
8.3
4
3.8
141
3.1
0.3
3.2
3.0
0.5
5.1
950
0.3
1.3
Marking
Pre Flow
Pressure
(N₂)
Marking Flow Rates /
Pressures
Arc
Voltage
Marking
Height
Pierce Ignition Height
THC and CNC
Delay
Control
Delay
Travel
Speed
Marking quality
degrades as
thickness
decreases.
16A Arc Current
Plasma (N₂)
Shield (N₂)
Burn-through may
happen for thicknesses
< 1/16” (0.063”) /
1.6mm.
(psi) /
(Bar)
Ball (psi) /
(Bar) Ball
(psi) /
(Bar) (Volts)
(in) ±0.005
/ (mm) ±0.1 (in) ±0.005 / (mm) ±0.1
(sec)
(sec)
(ipm) /
(mm/
min)
20 / 1.4
40
40 /
2.8
75
80 /
5.5
120 0.120 / 3.0
0.120 / 3.0
0
0.4
300 /
7620
BOLD TYPE indicates maximum piercing parameters.
* Pressure of the water supply line should be regulated by customer pressure regulator.
Note1: Ohmic height sensing is not recommended with water shield. Water on the plate interferes electrically with the ohmic sensing circuit.
Note2: Water source used for shield must be demineralized.
Electrode
Shield Cap
Tip
Shield Gas
Distributor
Plasma Gas
Distributor
Cartridge
Shield Cup
This Art Is For Reference ONLY
Art # A-07958_AB
