5.3 Menu organization
774 Oven Sample Processor, Instructions for use 65
>rack definitions 1
work position 0 mm
Working position of the lift (in mm from
the upper stop)
0…100 mm The working position is used for
sample determinations
Pressing directly accepts the current lift position.
>rack definitions 1
rinse position 0 mm
Rinsing position of the lift (in mm from
the upper stop)
0…100 mm The rinsing position is used for
the conditioning vessel
Pressing directly accepts the current lift position.
>rack definitions 1
shift position 0 mm
Shifting position of the lift (in mm from
the upper stop)
0…20 mm
Pressing directly accepts the current lift position.
>rack definitions 1
spezial position 0 mm
Special position of the lift (in mm from
the upper stop)
0…100 mm
Pressing directly accepts the current lift position.
>rack definitions 1
>>special positions
Special positions submenu
Open with
Position of special beaker 1
>>special positions
special beaker 1 36
0…number of positions
Position of special beaker 2
>>special positions
special beaker 2 0
0…Number of positions
etc. up to special beaker 8
Up to 8 special beaker positions can be defined. More information about
racks and special beakers is found on page 87ff.
configuration
>dosing units
Submenu for dosing unit settings
Open the submenu with
>dosing units
dosing unit 1
Select the dosing unit
(700 Dosino or 685 Dosimat)
1…12
The address of the dosing unit (see p. 19) must be confirmed with .
This will then be displayed in the first menu line.
