5.11 Description of the remote control commands
774 Oven Sample Processor, Instructions for use 129
5.11.6.7 Assembly.Scan $G, $S
Assembly.Scan.Address Rm, RS
Assembly.Scan.Pattern
with Rm (parallel/Remote): 8 x 1, 0 or ∗ (bin)
ready1, end1, Cond ok.
Cond 737, no error
with RS (serial/RS232): 14 ASCII characters
Scanning the interfaces.
.Address
Selection of interface (Remote / RS232)
.Pattern Signal or character string
This function is not applicable for process control via RS232 interface. See
&Info.ActualInfo.Inputs and …Outputs (5.11.3.14 and 5.11.3.15) instead.
5.11.6.8 Assembly.Ctrl $G
Assembly.Ctrl.Address Rm, RS
Assembly.Ctrl.Pattern
with Rm (parallel/Remote): 14 x 1, 0 or ∗ (bin),
START device1, START dos1,
STOP device1, ENTER, INIT
with RS (serial/RS232): 14 ASCII characters
Signal or data transmission via interfaces.
.Address
Interface selection (Remote/RS232)
.Pattern Signal or character string
With the Remote interface predefined bit patterns may be applied using the
short names listed above (see page 99ff).
5.11.6.9 Assembly.Def $G
Assembly.Def.Object DOSRATE
FILLRATE, LIFTRATE
SHIFTRATE, DRIVE.PORT
Assembly.Def.Address depending on .object
Assembly.Def.Value depending on .object
Definition of various device settings. Depending on the selected item in
…DEF.Object different parameters and ranges may be entered.
Def.Object Def.Address Def.Value
DOSRATE 1…12 0.01…160 ml/min
FILLRATE 1…12 0.01…160 ml/min
LIFTRATE 1…2 3…25 mm/s
SHIFTRATE auto., +, – 3…20 ang. degrees/s
DRIVE.PORT [1…12].[1…4] dos., fill, rinse, prep., drain
&Assembly.Def;$G triggers this function.
5.11.6.10 Assembly.Wait $G, $S, $H, $C
Assembly.Wait.Time 0...1...9999 s
Waiting time.
&Assembly.Wait;$G triggers this function.
5.11.6.11 Assembly.End $G
$G triggers a RESET (same as the key).
