5 Detailed description
774 Oven Sample Processor, Instructions for use 114
:
├ .Lift Moving the lift $G, $S 5.11.6.3
│ ├ .Station Lift address 1, 2, ∗
│ └ .Way Position work, rinse, shift, special,
│
rest, 0...325 mm
│
├ .Heater Temperature control $G 5.11.6.4
│ ├ .Temp Target temperature INIT, off, 50…250
│ └
.Time Heating interval blank, 1...999 min
│
├ .Flow Gas flow control $G 5.11.6.5
│ ├ .Address Pump or valve Pump, Valve
│ └
.State Status on, off
│
├ .Dos Initiate dosing functions $G, $S 5.11.6.6
│ ├ .Address Address of dosing unit 1...12
│ └
.Value Volume or function ±0.001...1...999.999 ml, fill,
│ release, prepar., empty, eject,
│ adjust, level
│
├ .Scan Scanning the interfaces $G, $S 5.11.6.7
│ ├ .Address Selection of interface Rm, RS
│ └ .Pattern Input signal or data
│ for Rm (Remote): 8 x 1, 0 or * (bin)
│ ready1, end1, Cond ok,
│
Cond 737, no error
│ for RS (RS232): 14 ASCII characters
│
├ .Ctrl Interface control $G 5.11.6.8
│ ├
.Address Interface selection Rm, RS
│ └ .Pattern Output signal or data
│ for Rm (Remote): 14 x 1, 0 or ∗ (bin),
│ START device1, START dos1
│
STOP device1, START 737
│ ENTER, INIT
│ for RS (RS232): 14 ASCII characters, &M;$G
│
├
.Def Re-definitions $G 5.11.6.9
│ ├ .Object Item selection DOSRATE, FILLRATE,
│ │ LIFTRATE, SHIFTRATE,
│ │ DRIVE.PORT
│ ├
.Adress Component address dependent upon item
│ └ .Value Value dependent upon item
│
├ .Wait Waiting time $G, $S, $H, $C 5.11.6.10
│ └ .Time Waiting time 0...1...9999 s
│
└ .End Changer RACK / RESET $G 5.11.6.11
