5.1 The display

774 Oven Sample Processor, Instructions for use

43







5 Detailed description

5.1 The display


The display consists of two lines, each having 24 characters.
The first line serves as a title line in which the current method and the sam-
ple counter reading are displayed. In edit mode the menu title is shown.
The second line serves as a status line which displays specific activities
depending on the operating state. In edit mode it serves as an entry line.

Normal state

sample

counter

Ð

method name Î

oven temperatur Î

******** counter 1/36

110°C 55 mL/min ready

Í

instrument status

Ï

gas flow


Method processing

running sequence Î

******** counter 2/36

START 03 WAIT 11 s

Í

parameter

Ï

current command with line number

Mesured values

gas flow 55 mL/min

oven temp. 110°C

Using key
