7
Control Modes & Guides
Integrated RGB Modes
Press Scene button on Wi-Fi-LED Controller
Mode (M) Description
1 Static Red
2 Static Blue
3 Static Green
4 Red/Yellow Alternate Fade
5 White Fade In/Out
6 RGB Fade In/Out
7 Yellow/Purple/Cyan Alternate Fade
8 7 Color Fade (R,G,B,Y,P,C,W)
9 7 Color Random Fade
RGB Mobile Remote Modes
(Located in the Style interface of the RGB Controller application)
Mode (M) Description Mode (M) Description
1 Static Red 17 Cyan Fade In/Out
2 Static Green 18 White Fade In/Out
3 Static Blue 19 RGB Fade In/Out
4 Static Yellow 20 Red/Green Alternate Fade
5 Static Purple 21 Red/Blue Alternate Fade
6 Static Cyan 22 Blue/Green Alternate Fade
7 Static White 23 Red/Yellow Alternate Fade
8 RGB Color Skip 24 Green/Cyan Alternate Fade
9 7 Color Skip (R,G,B,Y,P,C,W) 25 Blue/Purple Alternate Fade
10 White Strobe 26 Green/Yellow Alternate Fade
11 7 Color Strobe (R,G,B,Y,P,C,W) 27 Blue/Cyan Alternate Fade
12 Red Fade In/Out 28 Red/Purple Alternate Fade
13 Green Fade In/Out 29 Blue/White Alternate Fade
14 Blue Fade In/Out 30 Yellow/Purple/Cyan Alternate Fade
15 Yellow Fade In/Out 31 RGB Alternate Fade
16 Purple Fade In/Out 32 Full Color Fade
TROUBLESHOOTING
• LED lights do not light up or fixture does not emit correct colors: Make sure all connections are correct and secure (check for
backwards polarity) and your compatible DC12V~DC24V constant voltage power supply is connected to 120V AC power. The lead
wires of the fixture should be stripped properly so the copper wires make direct contact with the Wi-FI LED Controller terminal block. Be
sure a 12V DC driver is powering 12V DC fixtures or a 24V DC driver is powering 24V DC fixtures. Mixing and matching different voltage
power supplies and fixtures will result in incorrect light output and permanent damage to your LED fixtures.
• Lights are flickering: Check that you have a compatible DC12V~DC24V constant voltage power supply rated to power the attached
load. Our Magnetic Dimmable Drivers are not compatible with this product. Also, make sure all connections are secure.
If you have any other questions/concerns please contact technical support. We are more than happy to assist you with any technical
difficulties or concerns.
