Diode LED Mist-Resist User Manual
Rohs, Mist resist ember™ led strip light features, Product specifications

®
1.877.817.6028
www.diodeled.com
cut point
Actual width
size shown
0.3”
DIODELED.COM
1.877.817.6028
Input Voltage: 12V DC
LED Chip Type: 3528 SMD
Chips per foot: 9
Power Consumption per foot: 0.72W / 60mA
Rated Fixture Lumens per foot: 58
Luminous Efficacy: 80 lm
Field Cuttable: every 4 inches
LED Spacing: 1.3 in. (between centers)
Width: 0.3 in.
Height: 0.1 in.
Connectors: 12 in. DC plug on one end, 3 ft. 18/2 lead
wires on the other end
Spool Length: 16.4 ft.*
Max. Run: 16.4 ft.*
* Each 16.4 foot section needs to be separately wired to
the power supply.
Certifications: UL Component, RoHS
Dimmable: yes
Environment: Indoor
Warranty: 5 years
Ambient Operating Temp.:-4º ~ +176º F (-20° ~ +80° C)
Mounting: 3M Adhesive Sticky Backing
Rated Lamp Life: 50,000 hours
MIST RESIST EMBER™ LED STRIP LIGHT
FEATURES
EMBER Ambient Strip Light is ideal for those in need of a soft, low light linear installation. This LED strip is perfect for lighting
pathways, stairs, railings, or for ambient and subtle accent lighting. This LED tape comes with a 3M™ adhesive backing which allows easy
mounting almost anywhere, and emits light with a 120 degree light beam angle. The low profile of the EMBER Ambient Strip Light allows
for out-of-sight installation in many discreet locations and applications, and it’s even dimmable. The flexible design and efficiency of this
low wattage strip lighting make it ideal for ambient lighting.
Each spool comes with both a DC plug and lead wires attached that allow for easy connection to a power source, whether a 12V
Plug-In Adapter or Hard-Wired Driver, so it’s plug-and-play. It comes with a 3M™ adhesive backing which allows for easy mounting on a
clean, dry surface.
4” between cut points
1.3” between centers
RoHS
Compliant
PRODUCT SPECIFICATIONS
item #
length
color
color temp. lumens / ft. beam angle power consumption / ft. CRI LEDs / ft.
DI-1550
16.4’
warm white
2700k
58
120°
0.72W / 60mA
75
9
v.1.5
