INSTALLATION GUIDE

1 OF 2

MATTONE

DIRECT-WIRE LED STEP LIGHT FIXTURE

®

Read all warnings and installation instructions thoroughly.

WARNING

Safety & Warnings

• Install in accordance with the National Electric Code, and local

regulations.

• This product is intended to be installed and serviced by a qualified,

licensed electrician.

• This product is IP65 rated for outdoor applications when installed with

MATTONE Support Housing (housing box sold separately).

• Ensure applicable wire is installed between driver, fixture, and any

controls in between. When choosing wire, factor in voltage drop,

amperage rating, and type (in-wall rated, wet location rated, etc.).

Inadequate wire installation could overheat wires, and cause a fire.

• The MATTONE Support Housing must be grounded. Ensure to attach

earth ground to the MATTONE Support Housing.

• Do not install this product in an environment outside the listed ambient

temperature.

• Do not modify or disassemble this product beyond instructions or the

warranty will be void.

1. Turn off 120-277VAC power at circuit breaker.
2. Mount MATTONE Support Housing (DI-MATB-HOUS) to studs with

MATTONE Mounting Brackets (DI-MATB-HANG).

3. Pull main power cable through MATTONE Support Housing and attach

earth Ground to housing chassis.

4. Attach AC Hot to MATTONE light engine Hot (black). Attach AC Neutral

to light engine Neutral (white).

5. Insert light engine into support housing and attach faceplate with

included Allen screws (use included #3 Allen key).

6. Turn on 120-277VAC power at circuit breaker.

Input Voltage

100-277VAC, 50/60Hz

Power Consumption

3W / .025A

Ambient Temperature

-4°

~ 122°F (-20° ~ 50°C)

For full specifications, see the ‘Specification Sheet’ available at the online

product page.

Environment

Outdoor / wet location / IP65

Mounting

Mounts in the MATTONE Support Housing

(sold separately). Support Housing can be

installed with the MATTONE Mounting

Brackets (also sold separately).

Certifications

cULus Listed (USA & Canada) Surface

Mount Luminaire, UL # E336778.

Quick Specs

IG100214-1.2

Installation

Install in accordance with the NEC and local regulations.

See next page for wiring and mounting diagram.

120V

AC

Dry/Wet Location

WARNING

Shock Hazard. May result in serious injury or death.
