SPOTMOD™ 12V LED Fixture

READ ALL INSTRUCTIONS PRIOR TO INSTALLATION

TECHNICAL SPECIFICATIONS

• Diameter: 1.56 in.

• Depth: 1.11 in.

• Input Voltage: 12VDC

• Power Consumption: 2.13W

• Environment: Suitable for damp location

For surface mount-only.

WARNING! DO NOT CONNECT THIS

PRODUCT DIRECTLY TO 120VAC POWER!

• Turn power OFF at main breaker before servicing or install-

ing this product.

• This product is intended to be installed and serviced by a

qualified, licensed electrician.

• Install in accordance with the National Electric Code, and

local regulations.

• Install in a well-ventilated, combustion-free environment.
• Do not disassemble or modify this product beyond the

directions in this guide. Do not cut off the attached wet

location plug. Doing so will void the NRTL certification and

product warranty.

• Ensure applicable wire is installed between driver, fixture,

and any controls in between. When choosing wire, factor

in voltage drop, amperage rating, and type (in-wall rated,

wet location rated, etc.).

SAFETY & WARNINGS

MOUNTING

Prior to mounting, perform a dry assembly and confirm all

lighting and accessories are compatible, properly connect-

ed, and functional. Never mount or install when connected

to power.

To mount, use included mounting screws to secure the

fixture to desired surface.

TROUBLESHOOTING

Fixture does not light up: Turn OFF main power. Ensure all

polarities are correct and all connections are secure. Turn

main power ON.
Fixture is flickering: Ensure a compatible system is in-

stalled. If installing a dimmable system see the Magnetic

Dimmable Driver or REIGN Dimmer installation guides etc.

for more thorough wiring instructions. Ensure all connec-

tions are secure.
Fixture is overheating: Ensure fixture is installed in a well-

ventilated area. Ensure driver is not overloaded and wiring/

accessories are not exceeding their maximum amperage

rating.
Fixture turns ON and OFF continuously: Ensure driver is

not overloaded. Overloaded drivers will continuously turn

ON and OFF as a form of automatic reset protection.

For additional questions/concerns regarding installation or

operation of this product, please contact technical support.

Please have all product part numbers on hand for fast and

efficient technical assistance.

• Attached wires are not rated for installation behind walls

and ceilings. DC extension cables, connectors and other

accessories/components are not rated for in-wall instal-

lation unless otherwise noted.

• This product is not rated as submersible.
• Do not install near chlorinated or treated water.
• Suitable for surface-mount only. Do not recess-mount.

SAFETY & WARNINGS CONTINUED...

Rev 1.1, 2/5/14
