Diode LED SPOTMOD Recessed Gimbal Fixture User Manual
Diode LED Lighting

SPOTMOD™ Recessed Gimble 12V LED Fixture
READ ALL INSTRUCTIONS PRIOR TO INSTALLATION
TECHNICAL SPECIFICATIONS
• Recessed Diameter: 1.75 in.
• Input Voltage: 12VDC
• Power Consumption: 2.13W
• Angle Adjustable: +/- 20 °
• Environment: Suitable for damp location.
Not for in-ground installation.
WARNING! DO NOT CONNECT THIS
PRODUCT DIRECTLY TO 120VAC POWER!
• Turn power OFF at main breaker before servicing or install-
ing this product.
• This product is intended to be installed and serviced by a
qualified, licensed electrician.
• Install in accordance with the National Electric Code, and
local regulations.
• Install in a well-ventilated, combustion-free environment.
• Do not disassemble or modify this product beyond the
directions in this guide. Do not cut off the attached wet
location plug. Doing so will void the NRTL certification and
product warranty.
• Ensure applicable wire is installed between driver, fixture,
and any controls in between. When choosing wire, factor
in voltage drop, amperage rating, and type (in-wall rated,
wet location rated, etc.).
SAFETY & WARNINGS
MOUNTING
Prior to mounting, perform a dry assembly and confirm all
lighting and accessories are compatible, properly connect-
ed, and functional. Never mount or install when connected
to power.
To mount, drill a hole with a 1.75 in. hole saw (not
included). Squeeze mounting fins and recess the module
into the hole.
TROUBLESHOOTING
Fixture does not light up: Turn OFF main power. Ensure all
polarities are correct and all connections are secure. Turn
main power ON.
Fixture is flickering: Ensure a compatible system is in-
stalled. If installing a dimmable system see the Magnetic
Dimmable Driver or REIGN Dimmer installation guides etc.
for more thorough wiring instructions. Ensure all connec-
tions are secure.
Fixture is overheating: Ensure fixture is installed in a well-
ventilated area. Ensure driver is not overloaded and wiring/
accessories are not exceeding their maximum amperage
rating.
Fixture turns ON and OFF continuously: Ensure driver is
not overloaded. Overloaded drivers will continuously turn
ON and OFF as a form of automatic reset protection.
For additional questions/concerns regarding installation or
operation of this product, please contact technical support.
Please have all product part numbers on hand for fast and
efficient technical assistance.
• Attached wires are not rated for installation behind walls
and ceilings. DC extension cables, connectors and other
accessories/components are not rated for in-wall instal-
lation unless otherwise noted.
• This product is not rated as submersible.
• This product is not suitable for in-ground installation.
• Do not install near chlorinated or treated water.
SAFETY & WARNINGS CONTINUED...
Rev 1.1, 2/5/14
