INSTALLATION GUIDE RGB INLINE COLOR CONTROLLER
IG022614-1.0
Safety & Warnings
Before you begin, read all warnings and installation instructions thoroughly.
Prior to installation, verify all components are a compatible system. Configure and pre-test your LED system prior to permanent installation to ensure all
components are operating correctly. Install in accordance with the NEC and local regulations.
1. Turn OFF 120 ~277VAC power at circuit breaker prior to installation.
2. Remove the Input and Output cover ports of the receiver with a #2
Phillips head screwdriver. Connect a compatible constant voltage DC
driver to the receiver. See ‘Wiring Connections’.
3. Connect a compatible RGB fixture to the receiver. Utilize the V+, R, G,
B terminal ports for RGB fixtures. See ‘Wiring Connections’. Ensure not
to overload the receiver. In addition, do not exceed the maximum run
length of the fixture.
4. Install additional components and accessories. Once complete, turn
circuit breaker ON.
• Install in accordance with the National Electric Code, and local regulations.
• This product is intended to be installed and serviced by a qualified,
licensed electrician.
• Do not connect directly to high voltage 120V~277V power. Install with a
compatible Class 2 constant voltage LED driver (power supply).
• Only install compatible LED drivers and fixtures. Contact technical support
or visit the product page for compatible products.
• This product is rated for indoor installation and is not protected against
moisture.
• Proper heat dissipation will prolong the working lifespan of this product.
Install in a well-ventilated area free from explosive gases and vapors.
• Ensure applicable wire is installed between driver, fixture, and any controls
in between. When choosing wire, factor in voltage drop, amperage
rating, and type (in-wall rated, wet location rated, etc.). Inadequate wire
installation could overhead wires, and cause a fire.
• Do not modify or disassemble this product beyond instructions or the
warranty will be void.
RGB Remote Receiver
Installation
Quick Specs
Input Voltage 3VDC Battery (CR2032)
Transmitting Distance 130 ft.
Control Type
Pulse Width Modulation (PWM). 3-channel
RGB fixtures.
Ambient Temperature † -4° ~ 122°F (-20° ~ 50°C)
Input / Output Voltage 12-24VDC constant voltage
Max Current Load 3A x 3CH Max 9A
Max Output Power 108W/216W (12V/24V)
Ambient Temperature † -22° ~ 122°F (-30° ~ 50°C)
Environment Indoor / dry location
For full specifications, see the ‘Specification Sheet’ available at the online
product page.
† Do not install product in an environment outside the listed ambient
temperature. Ensure adequate airflow and heatsinking is considered
when mounting/installing.
• Pull out battery tab of the remote and power up remote and receiver.
• Long press the Learning ID button on the receiver for >5 seconds until
the red running light blinks rapidly. Immediately release the ‘Learning ID’
and short press it again.
• Now press a button on the remote to send a signal and the remote will
sync to the receiver. After 3 seconds the running light on the receiver
should blink at a normal rate (roughly 1 blink per second).
If installing multiple controllers and receivers, do not pair multiple remotes
to a single receiver. Each remote must be paired to a single receiver or the
system will function improperly. Reset the receiver to factory settings if
improper pairing is performed.
Pairing the Remote and Receiver Installing the Receiver
Resetting the Receiver to Factory Settings
• To reset the receiver, long press the Learning ID button on the receiver
for >10 seconds.
• During this period the running light will flash rapidly for <5 seconds. You
can release the ‘Learning ID’ once the rapid flashing slows to a normal
rate (roughly 1 blink per second).
• The receiver has now been reset to factory settings.
Resetting the Receiver to Factory Settings
See the online product page for video
tutorials or contact technical support.
Need Additional Assistance?
WARNING Shock Hazard. May result in serious injury or death.
