Table 5-24 Connection Instance Attributes (Instance 1)
Attrib Rule NV Name
Data
Type
Data Value
Instance 1
(Explicit) Instance 2 (Polled)
1 Get NV State USINT 3 = Established
(default) 1 = Configuring
2 Get NV Instance
Type USINT 0 (Explicit
Message) 1 (Poll Message)
3 Get NV Transport
Trigger USINT 83
HEX
82
HEX
or 83
HEX
4 Get NV Produced
Connection
ID UINT 10xxxxxxx011
BIN
xxxxxx =
Node Address
01111xxxxxx
BIN
xxxxxx =
Node Address
5 Get NV Consumed
Connection
ID UINT 10xxxxxxx100
BIN
xxxxxx =
Node Address
10xxxxxxx101
BIN
xxxxxx =
Node Address
6 Get NV Initial
Comm.
Character USINT 21
HEX
01
HEX
7 Get NV Produced
Connection
Size UINT 96 96
8 Get NV Consumed
Connection
Size UINT 0 0
9 Get/
Set NV Expected
Packet
Rate UINT 0x09C4 (default)
2500 ms 0
12 Get NV Watchdog
Timeout
Action USINT 1 (default) 0 = Timeout
13 Get NV Produced
Connection
Path
Length UINT 0 (default) 4
14 Get NV Produced
Connection
Path ARRAY
of:
USINT Empty (default)
15 Get NV Consumed
Connection
Path
Length UINT 0 (default) 0
16 Get NV Consumed
Connection
Path ARRAY
of:
USINT Empty (default)
17 Get NV Production
inhibit time UINT 0 (default) No
inhibit time 0 (default) No inhibit
time
