63
Table 5-19 Assembly Instance 101 (65
HEX
) Instance Attributes
Instance Type Byte bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
101
(0x65)
Input 0-1 Frequency1 V rms
2-3 Frequency1 I rms
4-5 Frequency1 Phase
6-7 Frequency1 Del. Power
8-9 Frequency1 R
10-11 Frequency1 X
12-13 Frequency2 V rms
14-15 Frequency2 I rms
16-17 Frequency2 Phase
18-19 Frequency2 Del. Power
20-21 Frequency2 R
22-23 Frequency2 X
24-25 Frequency3 V rms
26-27 Frequency3 I rms
28-29 Frequency3 Phase
30-31 Frequency3 Del. Power
32-33 Frequency3 R
34-35 Frequency3 X
36-37 Frequency4 V rms
38-39 Frequency4 I rms
40-41 Frequency4 Phase
42-43 Frequency4 Del. Power
44-45 Frequency4 R
46-47 Frequency4 X
48-49 Frequency5 V rms
50-51 Frequency5 I rms
52-53 Frequency5 Phase
54-55 Frequency5 Del. Power
56-57 Frequency5 R
58-59 Frequency5 X
60-61 Frequency6 V rms
62-63 Frequency6 I rms
64-65 Frequency6 Phase
66-67 Frequency6 Del. Power
68-69 Frequency6 R
70-71 Frequency6 X
72-73 Frequency7 V rms
74-75 Frequency7 I rms
76-77 Frequency7 Phase
78-79 Frequency7 Del. Power
80-81 Frequency7 R
82-83 Frequency7 X
84-85 Frequency8 V rms
86-87 Frequency8 I rms
88-89 Frequency8 Phase
90-91 Frequency8 Del. Power
92-93 Frequency8 R
94-95 Frequency8 X
