59
Assembly Instance 100 (64
HEX
) – BDS Standard Mode Data
This instance of the Assembly object is used to get all data produced by the BDS while running in the “Standard
Operating Mode”, including harmonics and intermods. The Standard Mode Data instance is selected by setting the
“Input Assembly Instance ID” to 100 (64
HEX
). The number of bytes produced per assembly object instance depends
on the Standard Mode configuration set using the class-level and instance attributes of the Standard Mode Object
(Class Code 105 (69
HEX
)).
Assembly Instance 100 (64
HEX
) Attributes (Input Assembly)
Min number of bytes produced: 10 (No measurement data)
Max number of bytes produced: 2,760 (5 fundamentals w/ 15 harmonics & 6 intermods each).
Assembly 100 (64
HEX
) Instance Byte Mapping
The byte mapping below describes the “full measurement suite” scenario of a configuration with 5 fundamentals
with 15 harmonics and 6 intermodualtion products each (a total of 110 measurements). Each instance has a 10-byte
dataset header followed by the measurement data. Use the “Num Measurements” class-level attribute to read the
number of measurements contained. Note that the measurement data is grouped by fundamental frequency.
Attrib Rule NV Name
Data
Type
Description Value
3 Get V Measurement
Dataset ARRAY
of:
USINT A complete measurement
dataset that includes status,
timestamp, attenuation
applied, and measurement
data for each selected
frequency component. See Assembly
Instance Byte
Mapping. And
Standard Mode
object.
