43
Indicators and Connectors
Indicator & Connector Specification
Calibrated Cable Set
Temperature/Data
Cable,Sensor
Interface
Temperature/Data
Cable, Receiver
Interface
Voltage Cable
Current Cable
Fischer WSO 102 A056-150 Connector
9-Pin D-Sub
RP-SMA, male (reverse polarized)
SMA, male
Sensor
Voltage Output
Current Output
Temperature/Data
Output
RP-SMA, female (reverse polarized)
SMA, female
Fischer DBPU102A056-1.30
Receiver
Voltage Input
Current Input
Temperature/Data
Input
Status Display
Ethernet
DeviceNet
Analog Input/Output
Power Indicator
Reset
Power
RP-SMA, female (reverse polarized)
SMA, female
9-pin D-sub
Four, Tri-color LEDs for health, two for DeviceNet Status
Two RJ-45 10/100 Connectors with LED status
Lumberg RSWF5-PCB 5-pin Circular Connector
High Density D-Sub, 15-pin
LED, Green
Recessed Push button
CPC 4-Pin Circular Connector
