56
Message Router Object – Class Code: 2 (02
HEX
)
Table 5-9 Message Router Class Attributes (Instance 0)
Table 5-10 Message Router Instance Attributes (Instance 1)
Table 5-11 Message Router Common Services
Table 5-12 Message Router Object Instances
DeviceNet Object – Class Code: 3 (03
HEX
)
Table 5-13 DeviceNet Class Attributes (Instance 0)
Attrib Rule NV Name Data Type Description Value
1 Get NV Revision UINT Revision level of this object. 1
Attrib Rule NV Name Data Type Description Value
1 Get NV Object
List STRUCT
of: A list of supported
objects. 10
Number UINT Number of
supported classes
in the classes array.
Classes ARRAY
of:UINT List of supported
class codes. 01h,02h,03h,04h,05
h,30h,64h,65h,68h,
69h
Service
Code
Class Instance Service Name Description of Service
14 (0x0E) Yes Yes Get_Attribute_Single Returns the contents of the
specified attribute.
Instance Name Description
1 BDS Message Router BDS Message Router instance.
Attrib Rule NV Name
Data
Type
Description Value
1 Get NV Revision UINT Revision level of this
object. 1
