Rockwell Automation Logix5000 Logix5000 Controllers Quick Start User Manual
Page 99
Publication 1756-QS001E-EN-P - October 2009
99
Document a Project Chapter 6
RSLogix 5000 software uses different colors for descriptions:
Turn Pass-Through and Append Descriptions On or Off
1. In RSLogix 5000 software, from the Tools menu, choose Options.
2. Select the Display.
3. Turn on (check) or turn off (uncheck) the desired options.
A description in this color
Is a
Gray
Pass-through description
Black
Manually entered description
