59

Publication 1756-QS001E-EN-P - October 2009

59

Chapter

4

Program an Equipment Phase

Use PhaseManager software to create an equipment phase and change the default settings for the equipment
phase.

What You Need

You need these items to complete the tasks in this manual:

• Personal computer running RSLogix 5000 software, version 16 or later

• A layout of the system for which you are creating a project

Follow These Steps

5. Create an equipment phase (page

60

).

6. Create a state routine (page

60

).

7. Manually step through the states (page

61

).

8. Configure the initial state for an equipment phase (page

63

).

9. Open the configuration for an equipment phase (page

64

).

10. Configure an equipment phase (page

64

).
