Publication 1756-QS001E-EN-P - October 2009 13
Program and Test a Simple Project Chapter 1
Follow These Steps
1. Create a project for the controller (page 14 ).
2. Add I/O modules (page 15 ).
3. Look at I/O data (page 17 ).
4. Enter ladder logic (page 19 ).
5. Enter a function block diagram (page 21 ).
6. Assign alias tags for your devices (page 25 ).
7. Establish a serial connection to the controller (page 28 ).
8. Download a project to the controller (page 30 ).
9. Select the operating mode of the controller (page 32 ).
