Program Add-On Instructions
With version 16 of RSLogix 5000 programming software, you can design and configure sets of commonly
used instructions to increase project consistency. Similar to the built-in instructions contained in Logix5000
controllers, these instructions you create are called Add-On Instructions.
With Add-On Instructions, you can:
• insert your own instruction.
• copy an Add-On Instruction definition from another RSLogix 5000 project.
• import an Add-On Instruction definition from another RSLogix 5000 project.
What You Need
You need these items to complete the tasks in this manual:
• Personal computer running RSLogix 5000 software, version 16 or later
• A layout of the system for which you are creating a project
Follow These Steps
4. Insert an Add-On Instruction (page 52 ).
5. Copy an Add-On Instruction definition (page 53 ).
6. Import an Add-On Instruction definition (page 54 ).
7. Access a parameter that is not visible (page 55 ).
8. Monitor or change the value of a parameter (page 56 ).
9. View the logic of an Add-On Instruction (page 57 ).
10. Edit and monitor an Add-On Instruction (page 58 ).
11. Update an Add-On Instruction to a newer revision (page 58 ).
