Publication 1394-IN024B-EN-P — February 2004
Commissioning Your 1394 SERCOS Interface System 1-21
5. Observe the status LEDs on the axis modules.
6. Disconnect the load from the motor(s).
7. Apply main input power.
8. Verify that the main input phase-to-phase voltage is present at the
input terminals of the system module or at the user-supplied input
contactor.
9.
If the axis module
LED: Then:
Alternates red and
green
Axis module ready. Go to step 7.
Does not alternates red
and green Go to the chapter Troubleshooting Your
1394 SERCOS Interface System.
ATTENTION
!
To avoid personal injury or damage to
equipment, disconnect the load from the
motor(s). Ensure each motor is free of all
linkages when initially applying power to the
system.
If the voltage
measured between
terminals: Is: Then:
U and W
324-528V ac Go to step 9.
Not within
324-528V ac
Go to the chapter
Troubleshooting Your
1394 SERCOS Interface
System.
If the voltage
measured between
terminals: Is: Then:
V and W
324-528V ac Go to step 10.
Not within
324-528V ac
Go to the chapter
Troubleshooting Your
1394 SERCOS Interface
System.
