Understanding 1394 connectors, System module connectors, Axis module connectors – Rockwell Automation 1394 SERCOS Interface Multi-Axis Motion Control System User Manual
Page 11: Understanding 1394 connectors -3, System module connectors axis module connectors
Publication 1394-IN024B-EN-P — February 2004
Commissioning Your 1394 SERCOS Interface System
1-3
Understanding 1394
Connectors
The following tables provide a brief description of the 1394
connectors.
System Module Connectors
Axis Module Connectors
Description
Connector
Present on this 1394
System Module
Input Power
4-position connector housing
1394C-SJT05-D /
1394C-SJT10-D
Logic Power
2-position connector housing
Shunt Power
3-position connector housing
Logic, Shunt, and Input Power
Terminal Block
8-position terminal block
1394C-SJT22-D
Single Point Bond Bar
5-position grounding bar
1394C-SJT05-D,
1394C-SJT10-D, or
1394C-SJT22-D
Motor/Auxiliary Feedback
13-position connector housing
Relay Outputs
10-position connector housing
Analog Outputs
9-position connector housing
Discrete Input
8-position connector housing (4)
SERCOS Transmit and Receive
SERCOS fiber-optic (2)
DPI/SCANport
DPI/SCANport
Description
Connector
Motor Power Terminal Block
6-position terminal block
Motor Brake/Thermal (TB1/TB2)
4-position connector housing (2)
