2-14 Install the ULTRA Plus PDM Components
1398-PDM-25, 50, 100, and 150 Power Supply Module
7KH SRZHU VXSSO\ PRGXOH VKRXOG EH FHQWUDOO\ ORFDWHG WR PLQLPL]H WKH GLVWDQFH
EHWZHHQ LW DQG WKH 3'0 PRGXOHV 7KH KLJKHU FXUUHQW UDWLQJ 3'0 PRGXOHV
VKRXOG EH ORFDWHG FORVHVW WR WKH SRZHU VXSSO\ PRGXOH
PSM Auxiliary Transformers
)LJXUH VKRZV WKH PRXQWLQJ GLDJUDP DQG FRQQHFWLRQV IRU WKH 360
$X[LOLDU\ 7UDQVIRUPHU
Figure 2.9
PSM Auxiliary Transformer mounting
9101-0233
1.
5.00 MAX
4.38
5.50 MAX.
4.25 6.25
1.
8.0 MIN. CLEARANCE RECOMMENDED FOR ACCESS TO WIRING
RING OR SPADE LUG CONNECTORS (NOT PROVIDED) ARE REQUIRED
FOR WIRING CONNECTIONS TO THE TRANSFORMER.
INPUT (PRIMARY) CONNECTIONS: H1,H4
480 VAC INPUT: JUMPER H3 to H2
240 VAC INPUT: JUMPER H1 to H3 AND H2 to H4
OUTPUT (SECONDARY) CONNECTIONS: X1,X2
120 VAC
H1 H3 H2 H4
X1 X2
OUTPUT POWER @ 50/60Hz
110 VAC OUTPUT VOLTAGE
50˚C MAX. TEMPERATURE RISE 500 VA MIN.
NOMINAL OPERATING VOLTAGES 480 OR 240 INPUT, 120 OUTPUT
460 OR 230 INPUT, 115 OUTPUT
440 OR 220 INPUT, 110 OUTPUT
CONNECTION INSTRUCTIONS
X2 X1
H1 H2 H3 H4
MAX.
0.69
0.31
8-32 TERMINAL SCREWS (6)
NOTES:
SCHEMATIC SYMBOL
SPECIFICATIONS:
