Publication 1398-5.1 — January 2000
B-6 Options and Accessories
Motor Connectors 7KLV WDEOH OLVWV PRWRU FRQQHFWRUV IRU EXLOGLQJ FDEOHV IRU WKH + ) DQG 16HULHV
PRWRUV
Connector
Type Motor Series Straight Right Angle
Power
connectors H-Series (2000
and 3000) 9101-0325
(MS3106F18-4S) 9101-0398
(MS3108F18-4S
Power
connectors H and F-Series
(4000) 9101-0326
(MS3106F20-4S) 9101-0399
(MS3108F20-4S)
Power
connectors H and F-Series
(6000) 9101-0327
(MS3106F24-22S) 9101-0400
(MS3108F24-22S)
Power
connectors H-Series (8000) 9101-0328
(MS3106F32-17S) 9101-0401
(MS3108F32-17S)
Power
connectors N-Series 9101-1557 (Solder)
MS3116F14-5S (Solder)
MS3126F14-5S (Crimp)
KPT08F14-5S (Solder)
KPSE08F14-5S (Crimp) PT08E14-5S (Solder)
PT08SE14-5S (Crimp)
Encoder
connectors H-Series and
F-Series 9101-0329
MS3106F20-29S 9101-0402
MS3108F20-29S
Encoder
connectors N-Series 9101-1558 (Solder)
MS3116F14-19S (Solder)
MS3126F14-19S (Crimp)
KPT08F14-19S (Solder)
KPSE08F14-19S (Crimp) PT08E14-19S (Solder)
PT08SE14-19S (Crimp)
Brake connectors H-Series and
F-Series
9101-0330
MS3106F12S-3S 9101-0403
MS3108F12S-3S
Brake connectors N-Series 9101-1698 (Solder)
MS3116F12-3S (Solder)
MS3126F12-3S (Crimp)
KPT08F12-3S (Solder)
KPSE08F12-3S (Crimp) PT08E12-3S (Solder)
PT08SE12-3S (Crimp)
