Publication 1398-5.1 — January 2000
Options and Accessories B-7
Motor Shaft Seal Kits 7KLV WDEOH OLVWV PRWRU VKDIW VHDO NLWV DYDLODEOH IRU WKH + ) DQG 16HULHV
PRWRUV
Description (Outside Dia x Inside Dia x Width) Alternative Number
Shaft seal kit, H-2000 motor
22 mm x 12 mm x 7 mm 0041-5056
Shaft seal kit, H-3000 motor
28 mm x 15 mm x 7 mm 0041-5057
Shaft seal kit, H-4000 motor
47 mm x 20 mm x 7 mm 0041-5058
Shaft seal kit, H-6000 motor
80 mm x 38 mm x 8 mm 0041-5059
Shaft seal kit, H-8000 motor
85 mm x 45 mm x 8 mm W 0041-5053-005
Shaft seal kit, F-4000 motor
1.437 inch x 0.875 inch x 0.25 inch 0041-5060
Shaft seal kit, F-6000 motor
2.125 inch x 1.438 inch x 0.31 inch 0041-5061
Shaft seal kit, N-2300 motor mm/in
0.035 x 0.001 x 0.005 / 0.875 x 0.250 x 0.125 0041-5068
Shaft seal kit, N-3400 motor mm/in
0.044 x 0.019 x 0.010 / 1.125 x 0.500 x 0.250 0041-5069
Shaft seal kit, N-4200 motor mm/in
0.044 x 0.025 x 0.010 / 1.125 x 0.625 x 0.250 0041-5070
Shaft seal kit, N-5600 motor mm/in
0.054 x 0.030 x 0.010 / 1.375 x 0.750 x 0.250 0041-5071
Note: Shaft seals are manufactured to inch dimensions. Millimeter dimensions are
conversions from inches. Shaft seals require a lubricant to reduce wear. Lubricant is
provided with kit.
