1 Publication 1398-5.1 — January 2000
Appendix
A
Specifications
1398-PDM-10, 20, 30, 75, and
150B 7KH WDEOHV VWDUWLQJ EHORZ SURYLGH VSHFLILFDWLRQV IRU WKH 8/75$ 3OXV 3'0V
DQG WKHLU DFFHVVRULHV
1398-PDM-10, 20, 30, 75, and 150B Specifications
Drive
Module
Type 1398
PDM-10
(1
Φ
)
1398
PDM-20
(1
Φ
)
1398
PDM-30
(1
Φ
)
1398
PDM-75
(3
Φ
)
1398
PDM-150B
(3
Φ
)
Peak Output
Current/
Phase 10 amps 20 amps 30 amps 75 amps 150 amps
Continuous
Output
Current/
Phase 5 amps 10 amps 15 amps 35 amps 65 amps
Continuous
Output
Power 1 kW 2 kW 3 kW 7 kW 15 kW
Electrical Specifications
Line Voltage
Input
(50/60 Hz
)
100-240
VAC 100-240
VAC 100-240
VAC 100-240
VAC 100-240 VAC
Continuous
Shunt Power 50 W 50 W 50 W 50 W 180W
Peak Shunt
Power 4.5 kW 4.5 kW 4.5 kW 10 kW 19 kW
Continuous
Shunt
External 2.4 kW 2.4 kW 2.4 kW 4 kW 8 kW
Peak Shunt
External 6 kW 6 kW 6 kW 10 kW 19 kW
Physical Specifications
Weight 15 lb
(5 kg) 15 lb
(5 kg) 15 lb
(5 kg) 21 lb
10 kg 31 lb
14 kg
Operating
Temperature 32° to 140°F (0° to 50°C)
Storage
Temperature -40° to 176°F (-40° to 80°C)
