A-4 Specifications
Transformers
0XOWLWDS LVRODWLRQ WUDQVIRUPHUV DUH DYDLODEOH IRU OLQH YROWDJH PDWFKLQJ
Single Phase Transformer specifications
7KH 3'0 DQG XVH D VLQJOH SKDVH WUDQVIRUPHU
5HIHU WR 6LQJOH 3KDVH7UDQVIRUPHU /RDG 5HJXODWLRQ &XUYH RQ SDJH DQG
5HIHU WR 6LQJOH 3KDVH7UDQVIRUPHU 2XWOLQH 'LDJUDP RQ SDJH
Three Phase Transformer specifications
7KH 3'0 DQG KDYH D VHSDUDWH SRZHU VXSSO\ PRGXOH DQG
XVH D WKUHH SKDVH WUDQVIRUPHU 5HIHU WR 7KUHH 3KDVH7UDQVIRUPHU /RDG
5HJXODWLRQ &XUYHV RQ SDJH DQG 5HIHU WR 7KUHH 3KDVH 7UDQVIRUPHU 2XWOLQH
Specification
Value
Rating
3.0 kVA
Input
220/ 230/ 240/ 440/ 460/ 480 VAC RMS
Output
a
115/ 230 VAC RMS
Ambient temperature
32° to122°F (0° to 50°C)
Single phase input and output (50/60 Hz)
Specification
Model
TF-03
TF-06
TF-12
TF-18
Rating
3 kVA
6 kVA
12 kVA
18 kVA
Weight
86 lb
135 lb
200 lb
325 lb
31 kg
61 kg
91 kg
148 kg
Input
208/ 230/ 240/ 380/ 460/ 480 VAC RMS
Output
a
115/ 230 VAC RMS
Ambient temperature
32° to122°F (0° to 50°C)
Three phase input and output (50/60 Hz)
