Rockwell Automation 1398-PDM-xxx ULTRA Plus Series Positioning Drive Module - Manual (Page 139)

Publication 1398-5.1 — January 2000
Specifications A-3
Operator Terminals 7KH WZR RSWLRQDO RSHUDWRU WHUPLQDO VSHFLILFDWLRQV DUH FRPSDUHG LQ WKH
IROORZLQJ WDEOH
Fused
Disconnect Class RK5
40 amps Class RK5
90 amps
Output Bus
Voltage 100-340 VDC 100-340 VDC
Continuous
Output Current 50 amps 100 amps
Continuous
Shunt
Dissipation 600 W 1200 W
Peak Shunt
Power 20 kW 40 kW
Terminal Block
Torque 11.0 lb-in
(1.25 Nm) 24.0 lb-in
(2.75 Nm)
1398-PDM-25, 50, 100, and 150 Specifications (Continued)
Positioning
Drive Module 1398
PDM-25 1398
PDM-50 1398
PDM-100 1398
PDM-150
Operator Terminals
Terminal 1398-HMI-002 1398-HMI-003
Input voltage 110/240 VAC ±15% 24 VDC ±20% Nominal
Supply 25 Watts 0.5 Amps
Temperature
Operating
Storage
32° to 131°F (0° to 55°C) ambient
-40° to 158°F (-40° to 70°C)
ambient 32° to 104°F (0° to 40°C) ambient
4° to 176°F (-20° to 80°C) ambient
Humidity 5% to 95% non-condensing 80% maximum, non-condensing
Weight 7 lb. (3 kg) 2.3 lb. (0.1 kg)
Display Vacuum Fluorescent Display, 4
lines by 20 characters
Characters 5 mm high Vacuum Fluorescent Display, 4
lines by 20 characters
Characters 5 mm high
Front panel seal NEMA 4 (IP64)
NEMA 12 (IP66)
NEMA 4/IP65
RS-232 cable 9101-2205 9101-2205
