Publication 1398-5.1 — January 2000
Options and Accessories B-5
Transformers
7KLV WDEOH OLVWV VLQJOH DQG WKUHH SKDVH WUDQVIRUPHUV WR EH XVHG ZLWK WKH
8/75$ 3OXV 3'0V
Motor Identification
Description
Alternate
Number
3 KVA three phase transformer
0020-5091-001
6 KVA three phase transformer
0020-5091-002
12 KVA three phase transformer
0020-5091-003
18 KVA three phase transformer
0020-5091-004
Auxiliary PSM transformer
0020-5093
3 KVA single phase transformer (1398 PDM-10, 20, 30 or 75)
0020-5097
FACTORY DESIGNATED SPECIAL OPTIONS
AA
=
STANDARD FLANGE
AN
=
NEMA56C FLANGE
OPTIONS
00
=
STANDARD
01
=
90 Vdc BRAKE
04
=
24 Vdc BRAKE
OPTICAL ENCODER LINE COUNT*
F
=
1000
H
=
2000 (S T A N D A R D
)
J
=
2500
K
=
5000
L
=
500
M
=
3000
N
=
1500
MOTOR WINDING K
E
DESIGNATOR
NOTE: SPECIAL ORDER WINDINGS AVAILABLE
FRAME SIZE
Series DESIGNATOR
F
=
FERRITE MAGNET
H
=
LOW INERTIA
N
=
NEMA
* Not all line counts are available on all motors
H - 4 0 3 0 - Q H 00
-
AA
