Publication 1398-5.1 — January 2000
B-2 Options and Accessories
I/F Conversion Card
7KLV WDEOH OLVWV WKH 9 6RXUFLQJ LQWHUIDFH FRQYHUVLRQ FDUG DQG LWV FRQQHFWLRQV
FDEOHV
Power Supply Modules
7KLV WDEOH OLVWV WKUHH SKDVH SRZHU VXSSOLHV DQG WKHLU IXVHV
Description
Alternate Number
I/F Conversion Card, 24V Sourcing
(1)
(1)
Required for compliance with the European Union Low Voltage Directive (LVD). It must be mounted in the same
enclosure as ULTRA Plus PDM.
9103-0152
Cable, I/F Conversion Card
3ft (1m),
44-0141-003
Cable I/F Conversion Card
10ft (3m),
44-0141-010
Item Number
Description
Alternate Number
1398-PSM-50
Power Supply Module
9101-3056
1398-PSM-125
Power Supply Module
9101-3057
Auxiliary PSM
9101-0439
Connector TB1, PSM Screw Terminal
9101-0111
1398-PSM-50 Fuse
Bussman KLM-8 or Littelfuse KLK D 8
9101-0225
1398-PSM-125 Fuse
Bussman KLM-20 or Littelfuse KLK D 20
9101-1076
Fuse F1, PSM-AUX
Bussman MDX-7 or Littelfuse 313 007
9101-0123
