Publication 1398-5.1 — January 2000
B-4 Options and Accessories
Cables 7KLV WDEOH OLVWV SRZHU FDEOHV EHWZHHQ WKH 3'0 7HUPLQDO %ORFN 7% DQG WKH
0RWRU 7KH ODVW WKUHH GLJLWV ;;; LQGLFDWH D VWDQGDUG FDEOH OHQJWK IW
P IW P IW P DQG IW P
PDM Motor Description Alternate
Number
1398-PDM-10,
20, 30 or 75 H-2000 or H-3000 Motor 9101-1080-XXX
1398-PDM-10,
20, 30 or 75 H-4000 or F-4000 Motor 9101-1081-XXX
ULTRA Series F-2000, 3000 or H-2000, 3000 9101-1381-XXX
ULTRA Series F-4000 or H-4000 9101-1382-XXX
ULTRA Series F-6000 or H-6000 9101-1383-XXX
ULTRA Series
Programming Terminal Cable (RS-232) (P6)
(1)
(1) RS-232 cables are available in 3m and 7m (10 and 25 ft) lengths only.
9101-2024-XXX
ULTRA Series Operator Terminal Cable (RS-232)
(P7) 9101-2025-XXX
ULTRA Series Motor Encoder Cable (P5
Connector) 9101-2027-XXX
ULTRA Series Control Station Cable 9101-2030-010
ULTRA Series Encoder Cable 9101-2031-XXX
1398-PDM-25, 50, 100 or 150 for H-3000 Motor
Power Cable with Motor Connector 9101-0250-XXX
1398-PDM-25, 50, 100 or 150 for H-4000/F-4000
Motor Power Cable 9101-0251-XXX
1398-PDM-25, 50, 100 or 150 for H-6000/F-6000
Motor Power Cable 9101-0252-XXX
1398-PDM-25, 50, 100 or 150 for H-8000 Motor
Power Cable 9101-0253-XXX
N-Series Motor Power Cable 9101-1676-XXX
ULTRA Series P4 to P4 Master/Follower Cable 9101-2127-002
ULTRA Series Motor Encoder Cable (P5
Connector) with right angle motor connector 9101-2135-025 or
9101-2135-050
N-Series Encoder Cable (P5 Connector) with right
angle motor connector 9101-1677-XXX or
9101-1679-XXX
1398 PDM-10, 20, 30 or 75 for H-6000/F-6000
Motor Power Cable 9101-2179-XXX
ULTRA Plus to I/O Conversion Card, 3-foot Cable 44-0141-003
ULTRA Plus to I/F 24V Conversion Card, 10-foot
Cable 44-0141-010
