Rockwell Automation 1398-PDM-xxx ULTRA Plus Series Positioning Drive Module User Manual
Page 31
Publication 1398-5.1 — January 2000
Install the ULTRA Plus PDM Components 2-13
Figure 2.8
1398-PDM-150B Mounting
POT1 POT2
POT3
P10
1
1
1
P9
P8
U87
U67
U66
U57
U57
U66
U87
U67
U10
U10
Ultra Plus Series
Allen-Bradley
S
R
T
DC Bus+
L2
L3
L1 Aux
L2/N Aux
DC Bus-
L1
100-240
V
ac 50/60 Hz
A
uxiliar
y
A
C Mains (30 Onl
y)
Motor
Internal
External Shunt
1
3
2
TB2
DC BUS
Status
P7
Serial 1
Auxiliary
P6
Serial 2
Computer
P5
Encoder 1
Motor
P4
Encoder 2
Auxiliary
P3
Status/Analog
I/O
P2
Digital Inputs
And Outputs
P1
Digital Inputs
WARNING: High Voltage May
Exist Up To Fifteen Minutes
After Removing Power.
TB1
FINAL INSPECTION
226.8
AIR INTAKE
AIR INTAKE
AIR INTAKE
AIR EXHAUST
8.93
14.20
360.7
151.7
5.97
2.75
69.9
2.75
69.9
31.8
1.25
0.27
7.0
13.75
349.2
[31.8]
[139.7]
1.25
5.50
