Rockwell Automation 1398-PDM-xxx ULTRA Plus Series Positioning Drive Module User Manual
Page 29

Publication 1398-5.1 — January 2000
Install the ULTRA Plus PDM Components 2-11
Figure 2.6
1398-PDM-75 Mounting
226.8
0.27
7.0
151.7
25.4
25.4
SW1
U10
AIR INTAKE
AIR INTAKE
AIR EXHAUST
FINAL INSPECTION
5
1
10
P1
Digital Inputs
1
5
And Outputs
Digital Inputs
P2
10
TB1
L2/N Aux
L1 Aux
L2/N
L3
L1
DC Bus-
DC Bus+
100-240
V
ac 50/60 Hz
DC Bus
Motor
T
S
R
Auxiliary
P3
Status/Analog
I/O
5
1
Encoder 1
P5
Motor
P4
Encoder 2
Computer
Serial 2
P6
After Removing Power
May Exist Up To Five Minutes
High Voltage
WARNING:
Status
TB2
P7
Serial 1
Auxiliary
Exter
n
al Shunt
Inter
nal
1
3
2
Ultra Plus Series
Allen-Bradley
5.97
1.99
50.5
1.00
1.00
8.93
14.20
360.7
13.75
349.2
