Preface
Contents of this Manual
Refer to the following listing for the descriptive contents of this
installation manual.
Product Receiving and
Storage Responsibility
You, the customer, are responsible for thoroughly inspecting the
equipment before accepting the shipment from the freight company.
Check the item(s) you receive against your purchase order. If any
items are obviously damaged, it is your responsibility to refuse
delivery until the freight agent has noted the damage on the freight
bill. Should you discover any concealed damage during unpacking,
you are responsible for notifying the freight agent. Leave the shipping
container intact and request that the freight agent make a visual
inspection of the equipment.
Store the product in its shipping container prior to installation. If you
are not going to use the equipment for a period of time, store using
the following guidelines.
•
Use a clean, dry location
•
Maintain an ambient temperature range of -40 to 70° C
(-40 to 158° F)
•
Maintain a relative humidity range of 5% to 95%, non-condensing
•
Store it where it cannot be exposed to a corrosive atmosphere
•
Store it in a non-construction area
Chapter
Title
Contents
Describes the purpose, background, and scope of
this manual. Also specifies the audience for
whom this manual is intended.
1
Installing Your 1394 SERCOS
Interface System
Provides system mounting information for the
1394 SERCOS interface components.
2
1394 SERCOS Interface
Connector Data
Provides system module and axis module
connector locations, signal descriptions, and I/O
specifications.
3
Connecting Your 1394 SERCOS
Interface System
Provides connection and wiring information for
the 1394 SERCOS interface components.
4
Troubleshooting Status
Indicators
Provides troubleshooting tables that define the
1394 status LEDs and fault codes.
Appendix A
Provides mounting dimensions, and power,
weight, environmental, and functional
specifications for the 1394.
Appendix B
Provides power, shunt, and drive/motor
interconnect diagrams for the 1394.
Appendix C
Catalog Numbers and
Accessories
Provides catalog numbers and descriptions of the
1394 and related products.
