Publication 1394-IN002B-EN-P — February 2004
Catalog Numbers and Accessories
C-3
Cables
Use the following tables to identify motor power, feedback, SERCOS
fiber-optic, and brake cables for your 1394 SERCOS interface system.
For standard available cable lengths, refer to the Motion Control
Selection Guide (publication GMC-SG001x-EN-P).
Motor Power Cables
1
High flex option for these cables is indicated by the letter T after CPx1. For example, 1326-CPx1T-RB-xxx.
2
IP67 environmental protection (single or double-ended) is available for these cables (used on -L motors) and
indicated by the letter L. For example, 1326-CPB1T-RBL-xxx.
Description
Catalog Number
MPL-Bxxxx or 1326AB (M2L/S2L) motors, non flex, 1.5 mm
2
(16 AWG), straight
2090-CDNBPMP-16Sxx
2090-XXNPMP-16Sxx
MPL-Bxxxx or 1326AB (M2L/S2L) motors, non flex, 6.0 mm
2
(10 AWG), straight
2090-CDNBPMP-10Sxx
1326AB-B4, -B5, and 1326AS-B3, -B4 motors
(resolver feedback), non flex, 1.5 mm
2
16 AWG
Single-ended
1326-CPB1-xxx
Double-ended
1326-CPB1-D-xxx
1, 2
Bulkhead connector
1326-CPB1-E-xxx
1, 2
Right-angle, shaft exit
1326-CPB1-RA-xxx
1, 2
Right-angle, rear exit
1326-CPB1-RB-xxx
1, 2
Double-ended bulkhead, flex (the -L
option is not available for this cable)
1326-CPB1T-EE-xxx
1326AB-B7, and 1326AS-B6, -B8 motors
(resolver feedback), non flex, 6.0 mm
2
10 AWG
Single-ended
1326-CPC1-xxx
1, 2
Double-ended
1326-CPC1-D-xxx
1, 2
Bulkhead connector
1326-CPC1-E-xxx
1, 2
Right-angle, shaft exit
1326-CPC1-RA-xxx
1, 2
Right-angle, rear exit
1326-CPC1-RB-xxx
1, 2
Double-ended bulkhead, flex (the -L
option is not available for this cable)
1326-CPC1T-EE-xxx
