Rockwell Automation 1394 SERCOS Interface Multi-Axis Motion Control System Installation Manual User Manual
Page 73

Publication 1394-IN002B-EN-P — February 2004
Connecting Your 1394 SERCOS Interface System
3-19
Wiring Logic Power
To wire the logic power terminal block:
1. Prepare the incoming 24V dc logic power wires for attachment to
the logic power terminals by removing 10 mm (0.375 in.) of
insulation.
2. Route the 24V dc power wires (W1 and W2) to your 1394 system
module.
3. Open the front door of the system module and locate the 22 kW
system module terminal blocks (refer to Figure 2.2).
4. Insert the incoming 24V dc logic power wires into the terminals as
follows and tighten the terminal block screws.
5. Gently pull on each wire to make sure it does not come out of its
terminal block. Re-insert and tighten any loose wires.
6. Go to the section Connecting Motor Power, Thermal Switch, and
IMPORTANT
Use caution not to nick, cut, or otherwise
damage strands as you remove the insulation.
Insert the wires labeled:
Into the terminal blocks labeled:
W1
W1
W2
W2
