1 Publication 1394-IN002B-EN-P — February 2004
Chapter
3
Connecting Your 1394 SERCOS Interface
System
Chapter Objectives This chapter covers the following topics:
•
Understanding Basic Wiring Requirements
•
Determining Your Type of Input Power
•
Setting the Ground Jumper in Ungrounded Power Configurations
•
Grounding Your 1394 SERCOS Interface System
•
Power Wiring Requirements
•
Connecting Input Power
•
Connecting Motor Power, Thermal Switch, and Brake
•
Understanding Feedback and I/O Cable Connections
•
Understanding External Shunt Connections
•
Connecting Your SERCOS Fiber-Optic Cables
Understanding Basic
Wiring Requirements This section contains basic wiring information for the 1394.
ATTENTION
!
Plan the installation of your system so that you can
perform all cutting, drilling, tapping, and welding
with the system removed from the enclosure.
Because the system is of the open type construction,
be careful to keep any metal debris from falling into
it. Metal debris or other foreign matter can become
lodged in the circuitry, which can result in damage to
components.
IMPORTANT
This section contains common PWM servo system
wiring configurations, size, and practices that can be
used in a majority of applications. National Electrical
Code, local electrical codes, special operating
temperatures, duty cycles, or system configurations
take precedence over the values and methods
provided.
