Factory and Field Parameter Settings
Appendix C
C-4
Factory and Field Parameter Settings -- Parameters 29Ć62
Function Parameter Parameter Factory Field
Group Number Name Units Range Setting Setting
Preset Frequency 29 PRESET FREQUENCY 2 Hertz 00.50/400.0 20.00
Settings 30 PRESET FREQUENCY 3 Hertz 00.50/400.0 30.00
3ĂI PRESET FREQUENCY 4 Hertz 00.50/400.0 40.00
32 PRESET FREQUENCY 5 Hertz 00.50/400.0 15.00
33 PRESET FREQUENCY 6 Hertz 00.50/400.0 25.00
34 PRESET FREQUENCY 7 Hertz 00.50/400.0 35.00
35 PRESET FREQUENCY 8 Hertz 00.50/400.0 45.00
Auxiliary Accel and Decel 36 ACCEL TIME 2 Seconds 000.1/1600 005.0
Settings 37 DECEL TIME 2 Seconds 000.1/1600 005.0
38 ACCEL TIME 3 Seconds 000.1/1600 005.0
39 DECEL TIME 3 Seconds 000.1/1600 005.0
40 ACCEL TIME 4 Seconds 000.1/1600 005.0
4ĂI DECEL TIME 4 Seconds 000.1/1600 005.0
Skip Frequency 42 SKIP FREQUENCY 1 Hertz 0000/400.0 0000
Settings 43 SKIP FREQUENCY 2 Hertz 0000/400.0 0000
44 SKIP FREQUENCY 3 Hertz 0000/400.0 0000
45 SKIP FREQUENCY BAND Hertz 0/10 0
Current Limit Setting 46 CURRENT LIMIT Seconds 00/1.5 00
Auto Restart Settings 47 POWER LOSS RESTART Code 0/1/2/3 1
48 RIDEĆTHRU RESTART Code 0/1/2 0
49 RESTART TIME SELECT Seconds 000.1/100.0 000.1
Lower and Upper 50 LOWER FREQUENCY CLAMP Hertz 00.50/400.0 00.50
Frequency Clamp Settings 5ĂI UPPER FREQUENCY CLAMP Hertz 00.50/400.0 400.0
Bias and Gain 52 BIAS AND GAIN ENABLE Off/On 0/1 0
Settings 53 BIAS FREQUENCY Hertz 00.00/400.0 00.00
54 GAIN FREQUENCY Hertz 00.50/400.0 60.00
Output Meter 55 FREQUENCY OUTPUT (AMPS) % of Max Output Signal 075/125 100
Settings 56 FREQUENCY OUTPUT (VOLTS) % of Max Output Signal 075/125 100
Monitoring Mode 57 MONITOR DISPLAY SELECT Code 0/1/2 0
Settings 58 MOTOR POLE SELECT Units 2/4/6/8/10 4
Drive Fault Memory 59 FAULT BUFFER 0 Code -- -- --
60 FAULT BUFFER 1 Code -- -- --
6ĂI FAULT BUFFER 2 Code -- -- --
62 FAULT BUFFER 3 Code -- -- --
