C
Appendix
C-1
Factory and Field Parameter Settings
Parameters Grouped by Function
The following tables in Appendix C provide parameter data grouped by
function. The function groups listed, reference the same parameters as
grouped in Chapters 5 and 6 and Appendix B.
Factory and Field Parameter Settings -- Pages C2 and C3
The table on the left provides parameter units, min/max values, factory
settings and room to record field settings.
Coordinated Parameter Settings -- Pages C4 and C5
The table on the right graphically shows which of the remaining
parameters must be checked to provide coordinated control of the Bulletin
1333 for each parameter.
For each parameter (numbered 0 I – 62 ) in the first column, a ■ in the
remaining columns (numbered 01-62) will indicate parameters that should
be checked to provide coordinated drive control.
