Factory and Field Parameter Settings
Appendix C
C-2
Factory and Field Parameter Settings -- Parameters 01Ć28
Function Parameter Parameter Factory Field
Group Number Name Units Range Setting Setting
Accel and Decel 0ĂI ACCEL TIME 1 Seconds 0000/1600 005.0
Settings 02 DECEL TIME 1 Seconds 0000/1600 005.0
VoltsĆperĆHertz Curve 03 FREQUENCY RANGE Code 50/60/FF 60
Settings 04 VOLTSĆPERĆHERTZ CURVE Code 0/1 0
DC Boost Setting 05 DC BOOST SELECT % of Output Voltage 00/40 00
Overload Protection 06 MOTOR DUTY Code 0/1/2/3 2
Settings 07 OVERLOAD CURRENT Amps 000.1/500.0 ❶
Local/Remote Control Enable 08 LOCAL/REMOTE CONTROL Code 0/1/2/3 0
Local/Remote Speed Enable 09 LOCAL/REMOTE FREQUENCY Code 0/1/2/3 0
Reverse Enable IĂ0 REVERSE LOCKOUT Off/On 0/1 0
Stop Setting IĂI STOP SELECT Code 0/1 0
DC Brake IĂ2 DC HOLD FREQUENCY Hertz 00.50/60.00 00.50
Settings IĂ3 DC HOLD TIME Seconds 000/10.0 000
IĂ4 DC HOLD VOLTS Code 0/10 0
Max Speed IĂ5 MAXIMUM FREQUENCY Hertz 50.00/400.0 60.00
Settings IĂ6 BASE FREQUENCY Hertz 50.00/250.0 60.00
Accel and Decel Hold IĂ7 ACCEL FREQUENCY HOLD Off/On 0/1 1
Enable IĂ8 DECEL FREQUENCY HOLD Off/On 0/1 1
Preset Frequency and IĂ9 FREQUENCY SELECT Code 0/1/2 0
Aux Accel/Decel Enable 20 TB15 PRESET/RESET Code 0/1 0
Aux Interlock Enable 2ĂI AUXILIARY INTERLOCK Code 0/1 0
Drive Supplied Contact 22 CR1 SELECT Code 1/2/3 1
Settings 23 CR2 SELECT Code 0/1/2/3 0
24 CR1 FREQUENCY Hertz 00.50/400.0 00.50
25 CR2 FREQUENCY Hertz 00.50/400.0 00.50
Jog 26 JOG FREQUENCY Hertz 00.50/20.00 10.00
Settings 27 JOG ACCEL TIME Seconds 0000/1600 005.0
28 JOG DECEL TIME Seconds 0000/1600 005.0
❶ Factory setting is determined by the output current rating shown on the drive nameplate.
