Rockwell Automation Publication 1441-UM001B-EN-P - September 2012 9
Preface
This manual covers the Dynamix™ 2500 data collector module which is used for
predictive maintenance using noise and vibration analysis.
When using the Dynamix 2500 data collector, you can do the following:
• Create lists of measurement definitions.
• Load lists from Emonitor® into the Dynamix 2500 data collector.
• Use an 80 Khz fmax, Route and Offroute.
• Collect magnitude, process, spectrum, time, and phase data.
• View selected alarms.
• Select inspection codes to store with a measurement.
• Define and collect unscheduled measurements
• Unload the data from the Dynamix 2500 data collector directly into the
Emonitor database.
• View the high resolution, up to 25,600 lines on the data collector.
Optional Extension
Modules These are the optional extension modules for the Dynamix 2500 data collector:
• 1441-DYN25-4C, 4-Channel Activation
(1)
The 4-channel activation lets you take 3 and 4 channel magnitude, time
waveform, spectra, and Offroute measurements.
• 1441-DYN25-MBMP Bump Test
A bump test (or hammer test) determines the natural frequencies of a
machine or a structure.
• 1441-DYN25-MBAL Balancing
Balancing application resolves single-plane, two-plane, and static-couple
balances with high precision.
• 1441-DYN25-MFRF Frequency Response Function
The FRF test lets you determine the natural frequencies of a machine as
well as sophisticated information about the frequency response of the
structure being tested.
• 1441-DYN25-MREC Time Recorder
The Time Recorder test uses a the instrument as a data recorder for real-
time data acquisition and analysis.
• 1441-DYN25-MRUC Run Up Coast Down
The RUCD test records and analyzes data from intermittent events and
transient vibration signals from non-steady state machines.
See Additional Resources on page 12 for a listing of available publications.
(1) This is an activation license for the Dynamix 2500 data collector.
