Collecting and Reviewing Data Chapter 5
Velocity Performs a standard acceleration to velocity vibration measurement.
These are the settings for the measurement parameters.
Accel Time Performs a standard vibration Acceleration measurement and collects waveform
data.
These are the settings for the measurement parameters.
Table 42 - Types of Offroute Measurements
Type Description
Parameter Value
Display Format Spectrum
Units A -> V
High-pass frequency 1.1 Hz
Input Channel X
Fmax 1 kHz
Lines/Samples 400 Lines
Averages 4
Overlap 50%
Type Spectral
Ext. Trigger Slope Positive
Trigger Level 2 V
Bin Zeroing On
Parameter Value
Display Format Time
Units Accel (G)
High-pass frequency 1.1 Hz
Input Channel X
Fmax 8 kHz
Lines/Samples 256…32768 samples
Averages 4 (time sync)
If a trigger is defined for the active Route
point, if no
trigger is detected only 1 average is
taken.
Overlap 50%
Type Time
Ext. Trigger Slope Positive
Trigger Level 2 V
